MCZ5606SC / MCZ5607SC

应用手册


概述/特点

The MCZ5606SC and MCZ5607SC are two-input/two-output high-side/low-side driver ICs for driving power devices such as power MOSFETs and IGBTs.
They incorporate a 622V withstand voltage level shift circuit and a 22V withstand voltage driver.
They are suitable for use in a wide range of applications, including inverter circuits and AC/DC or DC/DC power supplies. They incorporate a simultaneous ON prevention protection function to prevent through current occurring by canceling the output if ON signals are input to two input pins simultaneously.

1.　High-side withstand voltage: 622V
2.　2-input/2-output high-side/low-side driver
3.　Source current I_source = 220mA, sink current I_sink = 450mA
4.　ton=240ns、toff=270ns、tr=75ns、tf=30ns
5.　Supports both input 5V and input 3.3V logic
6.　Incorporates UVLO/simultaneous ON prevention protection function
7.　High-side dVS/dt tolerance: 50V/ns
8.　The MCZ5606SC and MCZ5607SC have different pin assignments.
